Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UMW Series
Standard Package	1000
Manufacturer	Nichicon
Series	UMW
Packaging	Tape & Box (TB)
Part Status	Active
Capacitance	220µF
Tolerance	±20%
Voltage - Rated	6.3V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	1000 Hrs @ 85°C
Operating Temperature	-40°C ~ 85°C
Polarization	Polar
Ratings	-
Applications	Audio
Ripple Current @ Low Frequency	110mA @ 120Hz
Ripple Current @ High Frequency	165mA @ 10kHz
Lead Spacing	0.138" (3.50mm)
Size / Dimension	0.315" Dia (8.00mm)
Height - Seated (Max)	0.236" (6.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UMW1E100MDD1TP	Nichicon, 10µF 25V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1C220MDD	Nichicon, 22µF 16V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW0J221MDD1TP	Nichicon, 220µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW0J331MDD1TP	Nichicon, 330µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW0J221MDD	Nichicon, 220µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1C470MDD1TP	Nichicon, 47µF 16V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1HR47MDD1TP	Nichicon, 0.47µF 50V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1E101MDD	Nichicon, 100µF 25V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW0J220MDD1TP	Nichicon, 22µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1H0R1MDD1TP	Nichicon, 0.1µF 50V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1A470MDD1TP	Nichicon, 47µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1C100MDD1TP	Nichicon, 10µF 16V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View

UMW0J221MDD1TP

Part NumberUMW0J221MDD1TP
