Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UMV Series
Standard Package	2000
Manufacturer	Nichicon
Series	UMV
Packaging	Tape & Box (TB)
Part Status	Not For New Designs
Capacitance	0.47µF
Tolerance	±20%
Voltage - Rated	50V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	5000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	3.8mA @ 120Hz
Ripple Current @ High Frequency	5.7mA @ 10kHz
Lead Spacing	0.059" (1.50mm)
Size / Dimension	0.157" Dia (4.00mm)
Height - Seated (Max)	0.236" (6.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UMV0J101MFD1TP	Nichicon, 100µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1H3R3MFD	Nichicon, 3.3µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1H4R7MFD1TP	Nichicon, 4.7µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1H2R2MFD	Nichicon, 2.2µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1H010MFD	Nichicon, 1µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV0G330MFD1TP	Nichicon, 33µF 4V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1C470MFD1TP	Nichicon, 47µF 16V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV0G101MFD1TP	Nichicon, 100µF 4V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1H100MFD	Nichicon, 10µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1HR22MFD1TP	Nichicon, 0.22µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1E330MFD1TP	Nichicon, 33µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV0G330MFD1TP	Nichicon, 33µF 4V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View

UMV1HR47MFD1TP

Part NumberUMV1HR47MFD1TP
