Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UMA Series
Standard Package	1
Manufacturer	Nichicon
Series	UMA
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	220µF
Tolerance	±20%
Voltage - Rated	4V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	2000 Hrs @ 85°C
Operating Temperature	-40°C ~ 85°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	96mA @ 120Hz
Ripple Current @ High Frequency	144mA @ 10kHz
Lead Spacing	0.098" (2.50mm)
Size / Dimension	0.248" Dia (6.30mm)
Height - Seated (Max)	0.236" (6.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UMA1V4R7MDD1TP	Nichicon, 4.7µF 35V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1V470MDD1TP	Nichicon, 47µF 35V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1E100MDD1TP	Nichicon, 10µF 25V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1V100MDD1TP	Nichicon, 10µF 35V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA0G221MDD1TP	Nichicon, 220µF 4V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1C4R7MCD2	Nichicon, 4.7µF 16V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1E470MDD1TP	Nichicon, 47µF 25V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1V2R2MCD2TP	Nichicon, 2.2µF 35V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1HR47MCD2TP	Nichicon, 0.47µF 50V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1HR22MCD2TP	Nichicon, 0.22µF 50V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1V220MDD1TP	Nichicon, 22µF 35V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View
UMA1C470MDD1TE	Nichicon, 47µF 16V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 85°C, UMA	View

UMA0G221MDD1TP

Part NumberUMA0G221MDD1TP
