Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UHW Series
Standard Package	50
Manufacturer	Nichicon
Series	UHW
Packaging	Bulk
Part Status	Active
Capacitance	4700µF
Tolerance	±20%
Voltage - Rated	16V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	10000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	3.048A @ 120Hz
Ripple Current @ High Frequency	3.81A @ 100kHz
Impedance	13 mOhms
Lead Spacing	0.295" (7.50mm)
Size / Dimension	0.630" Dia (16.00mm)
Height - Seated (Max)	1.063" (27.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UHW0J392MHD	Nichicon, 3900µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHW	View
UHW1J681MHD	Nichicon, 680µF 63V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHW	View
UHW1H471MPD	Nichicon, 470µF 50V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHW	View
UHW0J153MHD	Nichicon, 15000µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHW	View
UHW2A820MPD	Nichicon, 82µF 100V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHW	View
UHW1K181MHD6	Nichicon, 180µF 80V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHW	View
UHW2A391MHD6TN	Nichicon, 390µF 100V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHW	View
UHW1C472MHD6	Nichicon, 4700µF 16V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHW	View
UHW1J561MHD1TO	Nichicon, 560µF 63V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHW	View
UHW1K221MPD1TD	Nichicon, 220µF 80V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHW	View
UHW2A271MHD6TN	Nichicon, 270µF 100V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHW	View
UHW1E332MHD	Nichicon, 3300µF 25V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, UHW	View

UHW1C472MHD6

Part NumberUHW1C472MHD6
