Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	UF4001-G thru UF4008-G
Standard Package	5000
Manufacturer	Comchip Technology
Series	-
Packaging	Tape & Box (TB)
Part Status	Active
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	400V
Current - Average Rectified (Io)	1A
Voltage - Forward (Vf) (Max) @ If	1.3V @ 1A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)	50ns
Current - Reverse Leakage @ Vr	5µA @ 400V
Capacitance @ Vr, F	20pF @ 4V, 1MHz
Mounting Type	Through Hole
Package / Case	DO-204AL, DO-41, Axial
Supplier Device Package	DO-41
Operating Temperature - Junction	-55°C ~ 150°C
