Home/Product Catalog/Capacitors / Aluminum Electrolytic Capacitors/ UCX1C471MCL1GS

UCX1C471MCL1GS

UCX1C471MCL1GS

Part NumberUCX1C471MCL1GS

ManufacturerNichicon

DescriptionCAP ALUM 470UF 20% 16V SMD

DatasheetUCX Series

Package / CaseRadial, Can - SMD

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description470µF 16V Aluminum Electrolytic Capacitors Radial, Can - SMD 150mOhm 2000 Hrs @ 135°C

To learn about the specification of UCX1C471MCL1GS, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add UCX1C471MCL1GS with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of UCX1C471MCL1GS.
We are offering UCX1C471MCL1GS for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

UCX1C471MCL1GS - Product Attributes

Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UCX Series
Standard Package	1
Manufacturer	Nichicon
Series	UCX
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	470µF
Tolerance	±20%
Voltage - Rated	16V
ESR (Equivalent Series Resistance)	150mOhm
Lifetime @ Temp.	2000 Hrs @ 135°C
Operating Temperature	-40°C ~ 135°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	250mA @ 120Hz
Ripple Current @ High Frequency	500mA @ 100kHz
Lead Spacing	-
Size / Dimension	0.394" Dia (10.00mm)
Height - Seated (Max)	0.413" (10.50mm)
Surface Mount Land Size	0.406" L x 0.406" W (10.30mm x 10.30mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can - SMD
