TCE0806S-120-2P-T200

Part NumberTCE0806S-120-2P-T200

ManufacturerTDK Corporation

DescriptionCMC 100MA 2LN 12 OHM SMD ESD

DatasheetTCE0806S Series

Package / Case0302 (0806 Metric), 6 Lead

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description2 Line Common Mode Choke Surface Mount 12 Ohms @ 100MHz 100mA DCR 1Ohm

To learn about the specification of TCE0806S-120-2P-T200, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add TCE0806S-120-2P-T200 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of TCE0806S-120-2P-T200.
We are offering TCE0806S-120-2P-T200 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

TCE0806S-120-2P-T200 - Product Attributes

Categories

Filters / Common Mode Chokes

Datasheet

TCE0806S Series

Standard Package

10000

Manufacturer

TDK Corporation

Series

TCE

Packaging

Tape & Reel (TR)

Part Status

Not For New Designs

Filter Type

Signal Line

Number of Lines

Impedance @ Frequency

12 Ohms @ 100MHz

Current Rating (Max)

100mA

DC Resistance (DCR) (Max)

1Ohm

Voltage Rating - DC

10V

Voltage Rating - AC

Operating Temperature

-25°C ~ 85°C

Ratings

Approvals

Features

ESD

Mounting Type

Surface Mount

Size / Dimension

0.033" L x 0.026" W (0.85mm x 0.65mm)

Height (Max)

0.018" (0.45mm)

Package / Case

0302 (0806 Metric), 6 Lead
