SWT-0.85-680

Part NumberSWT-0.85-680

ManufacturerAmgis, LLC

DescriptionFIXED IND 680UH 850MA 1.25 OHM

DatasheetSW Series 50kHz

Package / CaseRadial, Horizontal (Open)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description680µH Unshielded Toroidal Inductor 850mA 1.25Ohm Max Radial, Horizontal (Open)

To learn about the specification of SWT-0.85-680, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SWT-0.85-680 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SWT-0.85-680.
We are offering SWT-0.85-680 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

SWT-0.85-680 - Product Attributes

Categories

Inductors, Coils, Chokes / Fixed Inductors

Datasheet

SW Series 50kHz

Standard Package

200

Manufacturer

Amgis, LLC

Series

Packaging

Tray

Part Status

Active

Type

Toroidal

Material - Core

Iron Powder

Inductance

680µH

Tolerance

±20%

Current Rating (Amps)

850mA

Current - Saturation

Shielding

Unshielded

DC Resistance (DCR)

1.25Ohm Max

Q @ Freq

Frequency - Self Resonant

Ratings

Operating Temperature

-40°C ~ 125°C

Inductance Frequency - Test

10kHz

Mounting Type

Through Hole

Package / Case

Radial, Horizontal (Open)

Supplier Device Package

Size / Dimension

0.701" L x 0.669" W (17.80mm x 17.00mm)

Height - Seated (Max)

0.422" (10.71mm)
