SRP1250-R68M


SRP1250-R68M

Part NumberSRP1250-R68M

Manufacturer

Description

Datasheet

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

SRP1250-R68M - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package500
ManufacturerBourns Inc.
SeriesSRP1250
PackagingTape & Reel (TR)
Part StatusActive
TypeWirewound
Material - CoreIron
Inductance680nH
Tolerance±20%
Current Rating (Amps)34A
Current - Saturation54A
ShieldingShielded
DC Resistance (DCR)1.7mOhm Max
Q @ Freq-
Frequency - Self Resonant-
Ratings-
Operating Temperature-55°C ~ 150°C
Inductance Frequency - Test100kHz
Mounting TypeSurface Mount
Package / CaseNonstandard
Supplier Device Package-
Size / Dimension0.547" L x 0.531" W (13.90mm x 13.50mm)
Height - Seated (Max)0.232" (5.90mm)
Base Part NumberSRP1250
