SRF1260-100M

Part NumberSRF1260-100M

ManufacturerBourns Inc.

DescriptionINDUCT ARRAY 2 COIL 10UH SMD

DatasheetSRF1260 Series

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionShielded 2 Coil Inductor Array 40µH Inductance - Connected in Series 10µH Inductance - Connected in Parallel 24.6mOhm Max DC Resistance (DCR) - Parallel 5.35A Nonstandard

To learn about the specification of SRF1260-100M, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SRF1260-100M with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SRF1260-100M.
We are offering SRF1260-100M for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

SRF1260-100M - Product Attributes

Categories	Inductors, Coils, Chokes / Arrays, Signal Transformers
Datasheet	SRF1260 Series
Standard Package	400
Manufacturer	Bourns Inc.
Series	SRF1260
Packaging	Tape & Reel (TR)
Part Status	Active
Number of Coils	2
Inductance - Connected In Parallel	10µH
Inductance - Connected In Series	40µH
Tolerance	±20%
Current Rating - Parallel	5.35A
Current Rating - Series	2.67A
Current Saturation - Parallel	7.17A
Current Saturation - Series	3.59A
DC Resistance (DCR) - Parallel	24.6mOhm Max
DC Resistance (DCR) - Series	93.4mOhm Max
Shielding	Shielded
Ratings	-
Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.492" L x 0.492" W (12.50mm x 12.50mm)
Height	0.244" (6.20mm)
Base Part Number	SRF1260
