SGNM100-10E
SGNM100-10E
Part Number SGNM100-10E
Description CAP TRIM 5-100PF 10KV CHAS MNT
Package / Case
Unit Price Request a Quote
Lead Time To be Confirmed
Detailed Description 5 ~ 100pF Trimmer Capacitor 10000V Top Chassis Mount
To learn about the specification of SGNM100-10E, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SGNM100-10E with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SGNM100-10E.
We are offering SGNM100-10E for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
SGNM100-10E - Product Attributes
Categories
Capacitors / Trimmers, Variable Capacitors
Datasheet SGNM100-10E Drawing
Standard Package 25
Manufacturer Sprague-Goodman
Series SGNM10KV
Part Status Active
Capacitance Range 5 ~ 100pF
Adjustment Type Top
Voltage - Rated 10000V
Dielectric Material Ceramic
Q @ Freq 500 @ 25MHz
Size / Dimension 0.710" Dia (18.03mm)
Height - Seated (Max) -
Operating Temperature -55°C ~ 125°C
Mounting Type Chassis Mount
Features Non-Magnetic, Sealed
