SG-9101CE-C20PHCCC

Part NumberSG-9101CE-C20PHCCC

ManufacturerEPSON

DescriptionXTAL OSC PROG XO CMOS CTR SPRD

DatasheetSG-9101Cx Series Datasheet

Package / Case4-SMD, No Lead

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionXO (Standard) CMOS 670kHz ~ 170MHz Programmable Oscillator 1.62V ~ 3.63V Enable/Disable 4-SMD, No Lead

To learn about the specification of SG-9101CE-C20PHCCC, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SG-9101CE-C20PHCCC with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SG-9101CE-C20PHCCC.
We are offering SG-9101CE-C20PHCCC for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

SG-9101CE-C20PHCCC - Product Attributes

Categories	Crystals, Oscillators, Resonators / Programmable Oscillators
Datasheet	SG-9101Cx Series Datasheet
Standard Package	1
Manufacturer	EPSON
Series	SG-9101
Packaging	Tube
Part Status	Active
Base Resonator	Crystal
Type	XO (Standard)
Programmable Type	Programmed by Digi-Key (Enter your frequency in Web Order Notes)
Available Frequency Range	670kHz ~ 170MHz
Function	Enable/Disable
Output	CMOS
Voltage - Supply	1.62V ~ 3.63V
Frequency Stability	-
Frequency Stability (Total)	-
Operating Temperature	-40°C ~ 105°C
Spread Spectrum Bandwidth	±2.00%, Center Spread
Current - Supply (Max)	-
Ratings	-
Mounting Type	Surface Mount
Package / Case	4-SMD, No Lead
Size / Dimension	0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max)	0.047" (1.20mm)
Current - Supply (Disable) (Max)	3.7mA
