SDE6603-102M
SDE6603-102M
Part Number SDE6603-102M
Description FIXED IND 1MH 70MA 13.8 OHM SMD
Package / Case Nonstandard
Unit Price Request a Quote
Lead Time To be Confirmed
Detailed Description 1mH Unshielded Wirewound Inductor 70mA 13.8Ohm Max Nonstandard
To learn about the specification of SDE6603-102M, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SDE6603-102M with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SDE6603-102M.
We are offering SDE6603-102M for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
SDE6603-102M - Product Attributes
Categories
Inductors, Coils, Chokes / Fixed Inductors
Datasheet SDE6603 Series
Standard Package 1
Manufacturer Bourns Inc.
Series SDE6603
Packaging Cut Tape (CT)
Part Status Active
Type Wirewound
Material - Core Ferrite
Inductance 1mH
Tolerance ±20%
Current Rating (Amps) 70mA
Current - Saturation 100mA
Shielding Unshielded
DC Resistance (DCR) 13.8Ohm Max
Q @ Freq -
Frequency - Self Resonant 2MHz
Ratings -
Operating Temperature -25°C ~ 105°C
Inductance Frequency - Test 100kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package -
Size / Dimension 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) 0.115" (2.92mm)
Base Part Number SDE6603
