Categories	Capacitors / Electric Double Layer Capacitors (EDLC), Supercapacitors
Datasheet	SCM Series Datasheet
Standard Package	270
Manufacturer	AVX Corporation
Series	SCM
Packaging	Bulk
Part Status	Active
Capacitance	1.5F
Tolerance	0%, +100%
Voltage - Rated	5.5V
ESR (Equivalent Series Resistance)	200mOhm @ 1kHz
Lifetime @ Temp.	2000 Hrs @ 65°C
Termination	PC Pins
Mounting Type	Through Hole
Package / Case	Radial, Can
Lead Spacing	0.453" (11.50mm)
Size / Dimension	0.728" L x 0.374" W (18.50mm x 9.50mm)
Height - Seated (Max)	1.004" (25.50mm)
Operating Temperature	-40°C ~ 65°C

SCMR22L105SSBB0	AVX Corporation, 1F (EDLC) Supercapacitor 9V Radial, Can 350mOhm @ 1kHz 2000 Hrs @ 65°C, SCM	View
SCMS32H505PRBB0	AVX Corporation, 5F (EDLC) Supercapacitor 6V Radial, Can 120mOhm @ 1kHz 2000 Hrs @ 65°C, SCM	View
SCMS32F505PRBA0	AVX Corporation, 5F (EDLC) Supercapacitor 5.5V Radial, Can 120mOhm @ 1kHz 2000 Hrs @ 65°C, SCM	View
SCMR14J334SSBA0	AVX Corporation, 330mF (EDLC) Supercapacitor 8.1V Radial, Can 500mOhm @ 1kHz 2000 Hrs @ 65°C, SCM	View
SCMR14C474PRBA0	AVX Corporation, 470mF (EDLC) Supercapacitor 5V Radial, Can 300mOhm @ 1kHz 2000 Hrs @ 65°C, SCM	View
SCMR22H155PRBB0	AVX Corporation, 1.5F (EDLC) Supercapacitor 6V Radial, Can 200mOhm @ 1kHz 2000 Hrs @ 65°C, SCM	View
SCMQ14F474PRBA0	AVX Corporation, 470mF (EDLC) Supercapacitor 5.5V Radial, Can 500mOhm @ 1kHz 2000 Hrs @ 65°C, SCM	View
SCMR14H474PRBB0	AVX Corporation, 470mF (EDLC) Supercapacitor 6V Radial, Can 380mOhm @ 1kHz 2000 Hrs @ 65°C, SCM	View
SCMS22H255PRBB0	AVX Corporation, 2.5F (EDLC) Supercapacitor 6V Radial, Can 180mOhm @ 1kHz 2000 Hrs @ 65°C, SCM	View
SCMT32C755SRBA0	AVX Corporation, 7.5F (EDLC) Supercapacitor 5V Radial, Can 70mOhm @ 1kHz 2000 Hrs @ 65°C, SCM	View
SCMT22C505PRBA0	AVX Corporation, 5F (EDLC) Supercapacitor 5V Radial, Can 100mOhm @ 1kHz 2000 Hrs @ 65°C, SCM	View
SCMR14G334SRBB0	AVX Corporation, 330mF (EDLC) Supercapacitor 7.5V Radial, Can 450mOhm @ 1kHz 2000 Hrs @ 65°C, SCM	View

SCMR22F155PSBA0

Part NumberSCMR22F155PSBA0
