SC54-100

Part NumberSC54-100

ManufacturerSignal Transformer

DescriptionFIXED IND 10UH 2.2A 100 MOHM SMD

DatasheetSC54 Series

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description10µH Unshielded Wirewound Inductor 2.2A 100mOhm Max Nonstandard

To learn about the specification of SC54-100, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SC54-100 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SC54-100.
We are offering SC54-100 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

SC54-100 - Product Attributes

Categories

Inductors, Coils, Chokes / Fixed Inductors

Datasheet

SC54 Series

Standard Package

1500

Manufacturer

Signal Transformer

Series

SC54

Packaging

Tape & Reel (TR)

Part Status

Active

Type

Wirewound

Material - Core

Inductance

10µH

Tolerance

±20%

Current Rating (Amps)

2.2A

Current - Saturation

1.44A

Shielding

Unshielded

DC Resistance (DCR)

100mOhm Max

Q @ Freq

Frequency - Self Resonant

Ratings

Operating Temperature

-40°C ~ 125°C

Inductance Frequency - Test

2.52MHz

Mounting Type

Surface Mount

Package / Case

Nonstandard

Supplier Device Package

Size / Dimension

0.240" L x 0.217" W (6.10mm x 5.50mm)

Height - Seated (Max)

0.189" (4.80mm)
