SC32-2R2

Part NumberSC32-2R2

ManufacturerSignal Transformer

DescriptionFIXED IND 2.2UH 1.7A 84 MOHM SMD

DatasheetSC32 Series

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description2.2µH Unshielded Wirewound Inductor 1.7A 84mOhm Max Nonstandard

To learn about the specification of SC32-2R2, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SC32-2R2 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SC32-2R2.
We are offering SC32-2R2 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

SC32-2R2 - Product Attributes

Categories

Inductors, Coils, Chokes / Fixed Inductors

Datasheet

SC32 Series

Standard Package

2500

Manufacturer

Signal Transformer

Series

SC32

Packaging

Tape & Reel (TR)

Part Status

Active

Type

Wirewound

Material - Core

Inductance

2.2µH

Tolerance

±20%

Current Rating (Amps)

1.7A

Current - Saturation

1.6A

Shielding

Unshielded

DC Resistance (DCR)

84mOhm Max

Q @ Freq

Frequency - Self Resonant

Ratings

Operating Temperature

-40°C ~ 125°C

Inductance Frequency - Test

7.96MHz

Mounting Type

Surface Mount

Package / Case

Nonstandard

Supplier Device Package

Size / Dimension

0.150" L x 0.130" W (3.80mm x 3.30mm)

Height - Seated (Max)

0.094" (2.40mm)
