Categories	Capacitors / Aluminum - Polymer Capacitors
Datasheet	RNU Series Datasheet
Standard Package	2000
Manufacturer	Nichicon
Series	FPCAP, RNU
Packaging	Tape & Box (TB)
Part Status	Active
Type	Polymer
Capacitance	100µF
Tolerance	±20%
Voltage - Rated	16V
ESR (Equivalent Series Resistance)	25mOhm
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	282mA @ 120Hz
Ripple Current @ High Frequency	2.82A @ 100kHz
Lead Spacing	0.098" (2.50mm)
Size / Dimension	0.248" Dia (6.30mm)
Height - Seated (Max)	0.453" (11.50mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

RNU1H390MDN1KX	Nichicon, 39µF 50V Aluminum Polymer Capacitor Radial, Can 25mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1E391MDNASQPH	Nichicon, 390µF 25V Aluminum Polymer Capacitor Radial, Can 14mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1E391MDN1PH	Nichicon, 390µF 25V Aluminum Polymer Capacitor Radial, Can 14mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1E331MDN1PH	Nichicon, 330µF 25V Aluminum Polymer Capacitor Radial, Can 14mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1E391MDNASQ	Nichicon, 390µF 25V Aluminum Polymer Capacitor Radial, Can 14mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU0E152MDN1KX	Nichicon, 1500µF 2.5V Aluminum Polymer Capacitor Radial, Can 7mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU0J152MDN1	Nichicon, 1500µF 6.3V Aluminum Polymer Capacitor Radial, Can 7mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU0J821MDN1KX	Nichicon, 820µF 6.3V Aluminum Polymer Capacitor Radial, Can 7mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU0J122MDN1KX	Nichicon, 1200µF 6.3V Aluminum Polymer Capacitor Radial, Can 9mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1V470MDN1KX	Nichicon, 47µF 35V Aluminum Polymer Capacitor Radial, Can 24mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU1E330MDN1KX	Nichicon, 33µF 25V Aluminum Polymer Capacitor Radial, Can 24mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View
RNU0G122MDN1KX	Nichicon, 1200µF 4V Aluminum Polymer Capacitor Radial, Can 7mOhm 2000 Hrs @ 105°C, FPCAP, RNU	View

RNU1C101MDS1JX

Part NumberRNU1C101MDS1JX
