RF1501NS3STL
RF1501NS3STL
Part Number RF1501NS3STL
Description DIODE GEN PURP 300V 20A LPDS
Package / Case TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Unit Price Request a Quote
Lead Time To be Confirmed
Detailed Description Diode Standard 300V 20A Surface Mount LPDS
To learn about the specification of RF1501NS3STL, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add RF1501NS3STL with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of RF1501NS3STL.
We are offering RF1501NS3STL for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
RF1501NS3STL - Product Attributes
Categories
Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet RF1501NS3S
Standard Package 1
Manufacturer Rohm Semiconductor
Series -
Packaging Cut Tape (CT)
Part Status Not For New Designs
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 300V
Current - Average Rectified (Io) 20A
Voltage - Forward (Vf) (Max) @ If 1.5V @ 20A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 30ns
Current - Reverse Leakage @ Vr 10µA @ 300V
Capacitance @ Vr, F -
Mounting Type Surface Mount
Package / Case TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Supplier Device Package LPDS
Operating Temperature - Junction 150°C (Max)
Base Part Number RF1501NS3S
