Categories	Capacitors / Aluminum - Polymer Capacitors
Datasheet	PLX Series
Standard Package	500
Manufacturer	Nichicon
Series	PLX
Packaging	Tape & Box (TB)
Part Status	Active
Type	Polymer
Capacitance	47µF
Tolerance	±20%
Voltage - Rated	50V
ESR (Equivalent Series Resistance)	29mOhm
Lifetime @ Temp.	3000 Hrs @ 125°C
Operating Temperature	-55°C ~ 125°C
Ratings	-
Applications	General Purpose
Ripple Current @ High Frequency	2.6A @ 100kHz
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.394" Dia (10.00mm)
Height - Seated (Max)	0.512" (13.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

PLX1V390MCL1TD	Nichicon, 39µF 35V Aluminum Polymer Capacitor Radial, Can 33mOhm 3000 Hrs @ 125°C, PLX	View
PLX1H270MDL1	Nichicon, 27µF 50V Aluminum Polymer Capacitor Radial, Can 33mOhm 3000 Hrs @ 125°C, PLX	View
PLX1C221MDL1TD	Nichicon, 220µF 16V Aluminum Polymer Capacitor Radial, Can 25mOhm 3000 Hrs @ 125°C, PLX	View
PLX1E820MCL1TD	Nichicon, 82µF 25V Aluminum Polymer Capacitor Radial, Can 28mOhm 3000 Hrs @ 125°C, PLX	View
PLX1H270MDL1TD	Nichicon, 27µF 50V Aluminum Polymer Capacitor Radial, Can 33mOhm 3000 Hrs @ 125°C, PLX	View
PLX1C391MDL1	Nichicon, 390µF 16V Aluminum Polymer Capacitor Radial, Can 23mOhm 3000 Hrs @ 125°C, PLX	View
PLX1E820MCL1TD	Nichicon, 82µF 25V Aluminum Polymer Capacitor Radial, Can 28mOhm 3000 Hrs @ 125°C, PLX	View
PLX1E820MCL1	Nichicon, 82µF 25V Aluminum Polymer Capacitor Radial, Can 28mOhm 3000 Hrs @ 125°C, PLX	View
PLX1H470MDL1	Nichicon, 47µF 50V Aluminum Polymer Capacitor Radial, Can 29mOhm 3000 Hrs @ 125°C, PLX	View
PLX1E121MDL1TD	Nichicon, 120µF 25V Aluminum Polymer Capacitor Radial, Can 27mOhm 3000 Hrs @ 125°C, PLX	View
PLX1D271MDL1	Nichicon, 270µF 20V Aluminum Polymer Capacitor Radial, Can 24mOhm 3000 Hrs @ 125°C, PLX	View
PLX1V560MDL1	Nichicon, 56µF 35V Aluminum Polymer Capacitor Radial, Can 31mOhm 3000 Hrs @ 125°C, PLX	View

PLX1H470MDL1TD

Part NumberPLX1H470MDL1TD
