PF0552.152NL

Part NumberPF0552.152NL

ManufacturerPulse Electronics Power

DescriptionINDUCT ARRAY 2 COIL 1.5UH SMD

DatasheetPF0552NL, PF0553NL Series

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionShielded 2 Coil Inductor Array 5.9µH Inductance - Connected in Series 1.5µH Inductance - Connected in Parallel 2.9mOhm Max DC Resistance (DCR) - Parallel 12.4A Nonstandard

To learn about the specification of PF0552.152NL, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add PF0552.152NL with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of PF0552.152NL.
We are offering PF0552.152NL for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

PF0552.152NL - Product Attributes

Categories

Inductors, Coils, Chokes / Arrays, Signal Transformers

Datasheet

PF0552NL, PF0553NL Series

Standard Package

Manufacturer

Pulse Electronics Power

Series

PF0552NL

Packaging

Tray

Part Status

Active

Number of Coils

Inductance - Connected In Parallel

1.5µH

Inductance - Connected In Series

5.9µH

Tolerance

±20%

Current Rating - Parallel

12.4A

Current Rating - Series

6.2A

Current Saturation - Parallel

18.4A

Current Saturation - Series

9.2A

DC Resistance (DCR) - Parallel

2.9mOhm Max

DC Resistance (DCR) - Series

12mOhm Max

Shielding

Shielded

Ratings

Operating Temperature

-40°C ~ 125°C

Mounting Type

Surface Mount

Package / Case

Nonstandard

Size / Dimension

0.492" L x 0.492" W (12.50mm x 12.50mm)

Height

0.236" (6.00mm)
