PF0504.681NLT

Part NumberPF0504.681NLT

ManufacturerPulse Electronics Power

DescriptionFIXED IND 680NH 20A 2 MOHM SMD

DatasheetPF0504NL Series Datasheet

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description680nH Unshielded Wirewound Inductor 20A 2mOhm Max Nonstandard

To learn about the specification of PF0504.681NLT, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add PF0504.681NLT with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of PF0504.681NLT.
We are offering PF0504.681NLT for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

PF0504.681NLT - Product Attributes

Categories

Inductors, Coils, Chokes / Fixed Inductors

Datasheet

PF0504NL Series Datasheet

Standard Package

160

Manufacturer

Pulse Electronics Power

Series

PF0504NL

Packaging

Tape & Reel (TR)

Part Status

Active

Type

Wirewound

Material - Core

Inductance

680nH

Tolerance

±20%

Current Rating (Amps)

20A

Current - Saturation

64A

Shielding

Unshielded

DC Resistance (DCR)

2mOhm Max

Q @ Freq

Frequency - Self Resonant

Ratings

Operating Temperature

-40°C ~ 125°C

Features

Mounting Type

Surface Mount

Package / Case

Nonstandard

Supplier Device Package

Size / Dimension

0.730" L x 0.600" W (18.54mm x 15.24mm)

Height - Seated (Max)

0.450" (11.43mm)
