Categories	Capacitors / Aluminum - Polymer Capacitors
Datasheet	PCV Series Datasheet
Standard Package	1
Manufacturer	Nichicon
Series	PCV
Packaging	Cut Tape (CT)
Part Status	Active
Type	Polymer
Capacitance	270µF
Tolerance	±20%
Voltage - Rated	16V
ESR (Equivalent Series Resistance)	21mOhm
Lifetime @ Temp.	3000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Ratings	-
Applications	General Purpose
Ripple Current @ High Frequency	3.8A @ 100kHz
Lead Spacing	-
Size / Dimension	0.315" Dia (8.00mm)
Height - Seated (Max)	0.394" (10.00mm)
Surface Mount Land Size	0.327" L x 0.327" W (8.30mm x 8.30mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can - SMD

PCV1E151MCL7GS	Nichicon, 150µF 25V Aluminum Polymer Capacitor Radial, Can - SMD 23mOhm 3000 Hrs @ 105°C, PCV	View
PCV1H8R2MCL1GS	Nichicon, 8.2µF 50V Aluminum Polymer Capacitor Radial, Can - SMD 81mOhm 3000 Hrs @ 105°C, PCV	View
PCV1H680MCL2GS	Nichicon, 68µF 50V Aluminum Polymer Capacitor Radial, Can - SMD 29mOhm 3000 Hrs @ 105°C, PCV	View
PCV1H120MCL2GS	Nichicon, 12µF 50V Aluminum Polymer Capacitor Radial, Can - SMD 55mOhm 3000 Hrs @ 105°C, PCV	View
PCV1C560MCL1GS	Nichicon, 56µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 50mOhm 3000 Hrs @ 105°C, PCV	View
PCV1D151MCL1GS	Nichicon, 150µF 20V Aluminum Polymer Capacitor Radial, Can - SMD 33mOhm 3000 Hrs @ 105°C, PCV	View
PCV1J220MCL6GS	Nichicon, 22µF 63V Aluminum Polymer Capacitor Radial, Can - SMD 37mOhm 3000 Hrs @ 105°C, PCV	View
PCV1C391MCL2GS	Nichicon, 390µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 20mOhm 3000 Hrs @ 105°C, PCV	View
PCV1E391MCL2GS	Nichicon, 390µF 25V Aluminum Polymer Capacitor Radial, Can - SMD 21mOhm 3000 Hrs @ 105°C, PCV	View
PCV1V181MCL2GS	Nichicon, 180µF 35V Aluminum Polymer Capacitor Radial, Can - SMD 22mOhm 3000 Hrs @ 105°C, PCV	View
PCV1C681MCL2GS	Nichicon, 680µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 19mOhm 3000 Hrs @ 105°C, PCV	View
PCV1C471MCL1GS	Nichicon, 470µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 25mOhm 3000 Hrs @ 105°C, PCV	View

PCV1C271MCL7GS

Part NumberPCV1C271MCL7GS
