Categories	Filters / Ferrite Beads and Chips
Datasheet	MPZ1005-V Series, Commercial
Standard Package	10000
Manufacturer	TDK Corporation
Series	MPZ-V
Packaging	Tape & Reel (TR)
Part Status	Active
Filter Type	Power Line
Number of Lines	1
Impedance @ Frequency	30 Ohms @ 100MHz
Current Rating (Max)	600mA
DC Resistance (DCR) (Max)	450mOhm
Ratings	-
Operating Temperature	-55°C ~ 125°C
Package / Case	0402 (1005 Metric)
Mounting Type	Surface Mount
Height (Max)	0.022" (0.55mm)
Size / Dimension	0.039" L x 0.020" W (1.00mm x 0.50mm)
