Categories	Discrete Semiconductor Products / Diodes - RF
Datasheet	MA4P MELF & HIPAX Series
Standard Package	1
Manufacturer	M/A-Com Technology Solutions
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
Diode Type	PIN - Single
Voltage - Peak Reverse (Max)	200V
Capacitance @ Vr, F	-
Resistance @ If, F	500mOhm @ 100mA, 100MHz
Power Dissipation (Max)	7.5W
Operating Temperature	-55°C ~ 175°C (TJ)
Package / Case	2-SMD, No Lead
Supplier Device Package	SMD

MA4AGBLP912	M/A-Com Technology Solutions, RF Diode PIN - Single 50V 40mA,	View
SMP1304-085LF	Skyworks Solutions Inc., RF Diode PIN - Single 200V 1.5A 2.5W 3-QFN (2x2),	View
MA4P7102F-1072T	M/A-Com Technology Solutions, RF Diode PIN - Single 200V 11.5W,	View
SMP1345-079LF	Skyworks Solutions Inc., RF Diode PIN - Single 50V 250mW SC-79,	View
SMP1304-027LF	Skyworks Solutions Inc., RF Diode PIN - 2 Pair CA + CC 200V 250mW SOT-5,	View
SMP1334-084LF	Skyworks Solutions Inc., RF Diode PIN - Single 200V 200mA 1W 2-QFN (2x2),	View
MA4PH237-1079T	M/A-Com Technology Solutions, RF Diode PIN - Single 200V 2W,	View
MA4P505-131	M/A-Com Technology Solutions, RF Diode PIN - Single 500V Die,	View
SMP1307-003LF	Skyworks Solutions Inc., RF Diode PIN - 1 Pair Common Anode 200V 250mW SOT-23-3,	View
SMP1307-006LF	Skyworks Solutions Inc., RF Diode PIN - 1 Pair Series Connection 200V 250mW SOT-23,	View
SMP1340-007LF	Skyworks Solutions Inc., RF Diode PIN - Single 50V 250mW SOT-23-3,	View
CLA4605-085LF	Skyworks Solutions Inc., RF Diode PIN - Single 60V 1.5A 1W 3-QFN (2x2),	View

MA4P4002F-1091T

Part NumberMA4P4002F-1091T
