Categories	Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Datasheet	MA46H120 Series
Standard Package	100
Manufacturer	M/A-Com Technology Solutions
Series	-
Packaging	Bulk
Part Status	Active
Capacitance @ Vr, F	0.2pF @ 10V, 1MHz
Capacitance Ratio Condition	-
Voltage - Peak Reverse (Max)	20V
Diode Type	Single
Q @ Vr, F	3000 @ 4V, 50MHz
Operating Temperature	-40°C ~ 125°C (TJ)
Mounting Type	Surface Mount
Package / Case	2-SMD
Supplier Device Package	-
