Categories	Crystals, Oscillators, Resonators / Oscillators
Datasheet	M100,170,200 Series Datasheet
Standard Package	250
Manufacturer	Connor-Winfield
Series	M100
Packaging	Tape & Reel (TR)
Part Status	Active
Base Resonator	Crystal
Type	TCXO
Frequency	12.8MHz
Function	-
Output	LVCMOS
Voltage - Supply	3.3V
Frequency Stability	±100ppb
Absolute Pull Range (APR)	-
Operating Temperature	0°C ~ 70°C
Current - Supply (Max)	3.3mA
Ratings	-
Mounting Type	Surface Mount
Package / Case	8-SMD, No Lead
Size / Dimension	0.197" L x 0.126" W (5.00mm x 3.20mm)
Height - Seated (Max)	0.083" (2.10mm)
Current - Supply (Disable) (Max)	-
