LGJ7045TS-220M1R3-H
LGJ7045TS-220M1R3-H
Part Number LGJ7045TS-220M1R3-H Description FIXED IND 22UH 1.25A 82 MOHM SMD Package / Case NonstandardUnit Price Request a QuoteLead Time To be ConfirmedDetailed Description 22µH Shielded Wirewound Inductor 1.25A 82mOhm Nonstandard
To learn about the specification of LGJ7045TS-220M1R3-H, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add LGJ7045TS-220M1R3-H with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of LGJ7045TS-220M1R3-H.
We are offering LGJ7045TS-220M1R3-H for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
LGJ7045TS-220M1R3-H - Product Attributes
Categories
Inductors, Coils, Chokes / Fixed Inductors
Datasheet LGJ7045TS-H Series Brief Standard Package 1 Manufacturer TDK Corporation Series LGJ Packaging Cut Tape (CT) Part Status Active Type Wirewound Material - Core Ferrite Inductance 22µH Tolerance ±20% Current Rating (Amps) 1.25A Current - Saturation 1.3A Shielding Shielded DC Resistance (DCR) 82mOhm Q @ Freq - Frequency - Self Resonant - Ratings AEC-Q200 Operating Temperature -40°C ~ 125°C Inductance Frequency - Test 100kHz Mounting Type Surface Mount Package / Case Nonstandard Size / Dimension 0.276" L x 0.276" W (7.00mm x 7.00mm) Height - Seated (Max) 0.189" (4.80mm)
