LGJ12575TS-150M4R7-H
LGJ12575TS-150M4R7-H
Part Number LGJ12575TS-150M4R7-H
Description FIXED IND 15UH 5A 18.4 MOHM SMD
Package / Case Nonstandard
Unit Price Request a Quote
Lead Time To be Confirmed
Detailed Description 15µH Shielded Wirewound Inductor 5A 18.4mOhm Nonstandard
To learn about the specification of LGJ12575TS-150M4R7-H, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add LGJ12575TS-150M4R7-H with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of LGJ12575TS-150M4R7-H.
We are offering LGJ12575TS-150M4R7-H for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
LGJ12575TS-150M4R7-H - Product Attributes
Categories
Inductors, Coils, Chokes / Fixed Inductors
Datasheet LGJ12575TS-H Series Brief
Standard Package 1
Manufacturer TDK Corporation
Series LGJ
Packaging Cut Tape (CT)
Part Status Active
Type Wirewound
Material - Core Ferrite
Inductance 15µH
Tolerance ±20%
Current Rating (Amps) 5A
Current - Saturation 4.7A
Shielding Shielded
DC Resistance (DCR) 18.4mOhm
Q @ Freq -
Frequency - Self Resonant -
Ratings AEC-Q200
Operating Temperature -40°C ~ 125°C
Inductance Frequency - Test 1kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Size / Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height - Seated (Max) 0.295" (7.50mm)
