KY16VB56RM5X11LL

Part NumberKY16VB56RM5X11LL

ManufacturerUnited Chemi-Con

To learn about the specification of KY16VB56RM5X11LL, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add KY16VB56RM5X11LL with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of KY16VB56RM5X11LL.
We are offering KY16VB56RM5X11LL for competitive price in the global market, please send us a quota request for pricing. Thank you!

Categories	Capacitors / Aluminum Electrolytic Capacitors
Standard Package	2000
Manufacturer	United Chemi-Con
Series	KY
Packaging	Bulk
Part Status	Obsolete
Capacitance	56µF
Tolerance	±20%
Voltage - Rated	16V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	5000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	84mA @ 120Hz
Ripple Current @ High Frequency	210mA @ 100kHz
Impedance	580 mOhms
Lead Spacing	0.079" (2.00mm)
Size / Dimension	0.197" Dia (5.00mm)
Height - Seated (Max)	0.433" (11.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can
