Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	1N5415 - 20
Standard Package	1
Manufacturer	Microsemi Corporation
Series	Military, MIL-PRF-19500/411
Packaging	Bulk
Part Status	Active
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	400V
Current - Average Rectified (Io)	3A
Voltage - Forward (Vf) (Max) @ If	1.5V @ 9A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)	150ns
Current - Reverse Leakage @ Vr	1µA @ 400V
Capacitance @ Vr, F	-
Mounting Type	Through Hole
Package / Case	B, Axial
Operating Temperature - Junction	-65°C ~ 175°C
