HVC0805Z1007JET

Part NumberHVC0805Z1007JET

ManufacturerOhmite

DescriptionRES SMD 1G OHM 5% 1/8W 0805

DatasheetHVC Series

Package / Case0805 (2012 Metric)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description1 GOhms ±5% 0.125W, 1/8W Chip Resistor 0805 (2012 Metric) High Voltage Thick Film

To learn about the specification of HVC0805Z1007JET, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add HVC0805Z1007JET with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of HVC0805Z1007JET.
We are offering HVC0805Z1007JET for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

HVC0805Z1007JET - Product Attributes

Categories	Resistors / Chip Resistor - Surface Mount
Datasheet	HVC Series
Standard Package	1
Manufacturer	Ohmite
Series	HVC
Packaging	Cut Tape (CT)
Part Status	Active
Resistance	1 GOhms
Tolerance	±5%
Power (Watts)	0.125W, 1/8W
Composition	Thick Film
Features	High Voltage
Temperature Coefficient	±250ppm/°C
Operating Temperature	-55°C ~ 155°C
Package / Case	0805 (2012 Metric)
Supplier Device Package	0805
Size / Dimension	0.079" L x 0.049" W (2.00mm x 1.25mm)
Height - Seated (Max)	0.022" (0.55mm)
Number of Terminations	2
Failure Rate	-
