Categories	Crystals, Oscillators, Resonators / Crystals
Datasheet	FW5000008Q Spec Sheet
Standard Package	1
Manufacturer	Diodes Incorporated
Series	SaRonix-eCera™ FW
Packaging	Cut Tape (CT)
Part Status	Active
Type	MHz Crystal
Frequency	50MHz
Frequency Stability	±15ppm
Frequency Tolerance	±10ppm
Load Capacitance	10pF
ESR (Equivalent Series Resistance)	60 Ohms
Operating Mode	Fundamental
Operating Temperature	-40°C ~ 85°C
Ratings	AEC-Q200
Mounting Type	Surface Mount
Package / Case	4-SMD, No Lead
Size / Dimension	0.079" L x 0.063" W (2.00mm x 1.60mm)
Height - Seated (Max)	0.022" (0.55mm)

FW4000044Q	Diodes Incorporated, 40MHz ±10ppm Crystal 8pF 50 Ohms 4-SMD, No Lead, SaRonix-eCera™ FW	View
FW2700019Z	Diodes Incorporated, 27MHz ±30ppm Crystal 20pF 50 Ohms 4-SMD, No Lead, SaRonix-eCera™ FW	View
FW3740001Z	Diodes Incorporated, 37.4MHz ±10ppm Crystal 18pF 60 Ohms 4-SMD, No Lead, SaRonix-eCera™ FW	View
FW2600055Q	Diodes Incorporated, 26MHz ±10ppm Crystal 10pF 90 Ohms 4-SMD, No Lead, SaRonix-eCera™ FW	View
FW4800010Z	Diodes Incorporated, 48MHz ±10ppm Crystal 10pF 80 Ohms 4-SMD, No Lead, SaRonix-eCera™ FW	View
FW4000015Q	Diodes Incorporated, 40MHz ±10ppm Crystal 8pF 50 Ohms 4-SMD, No Lead, SaRonix-eCera™ FW	View
FW2700019Z	Diodes Incorporated, 27MHz ±30ppm Crystal 20pF 50 Ohms 4-SMD, No Lead, SaRonix-eCera™ FW	View
FW1920009Q	Diodes Incorporated, 19.2MHz ±30ppm Crystal 10pF 150 Ohms 4-SMD, No Lead, SaRonix-eCera™ FW	View
FW2400063Q	Diodes Incorporated, 24MHz ±15ppm Crystal 18pF 90 Ohms 4-SMD, No Lead, SaRonix-eCera™ FW	View
FW1600029Q	Diodes Incorporated, 16MHz ±10ppm Crystal 8pF 150 Ohms 4-SMD, No Lead, SaRonix-eCera™ FW	View
FW2500039Q	Diodes Incorporated, 25MHz ±30ppm Crystal 18pF 80 Ohms 4-SMD, No Lead, SaRonix-eCera™ FW	View
FW2500022Q	Diodes Incorporated, 25MHz ±15ppm Crystal 20pF 80 Ohms 4-SMD, No Lead, SaRonix-eCera™ FW	View

FW5000008Q

Part NumberFW5000008Q
