FP1107R1-R15-R


FP1107R1-R15-R

Part NumberFP1107R1-R15-R

Manufacturer

Description

Datasheet

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

FP1107R1-R15-R - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package1
ManufacturerEaton - Electronics Division
SeriesFLAT-PAC, FP1107
PackagingCut Tape (CT)
Part StatusActive
TypeWirewound
Material - CoreFerrite
Inductance150nH
Tolerance±10%
Current Rating (Amps)55A
Current - Saturation70A
ShieldingUnshielded
DC Resistance (DCR)0.29mOhm
Q @ Freq-
Frequency - Self Resonant-
Ratings-
Operating Temperature-40°C ~ 125°C
Inductance Frequency - Test100kHz
Mounting TypeSurface Mount
Package / CaseNonstandard
Size / Dimension0.433" L x 0.283" W (11.00mm x 7.20mm)
Height - Seated (Max)0.295" (7.50mm)
