Categories	Capacitors / Film Capacitors
Datasheet	WIMA FKP 1
Standard Package	2000
Manufacturer	WIMA
Series	-
Packaging	Bulk
Part Status	Active
Capacitance	330pF
Tolerance	±5%
Voltage Rating - AC	700V
Voltage Rating - DC	2000V (2kV)
Dielectric Material	Polypropylene (PP), Metallized
Operating Temperature	-55°C ~ 100°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	0.709" L x 0.236" W (18.00mm x 6.00mm)
Height - Seated (Max)	0.492" (12.50mm)
Termination	PC Pins
Lead Spacing	0.591" (15.00mm)
Applications	High Frequency, Switching; High Pulse, DV/DT
Ratings	-
Features	-

FKP1U023307C00MSSD	WIMA, 0.033µF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
FKP1J016804C00KSSD	WIMA, 6800pF Film Capacitor 400V 630V Polypropylene (PP), Metallized Radial,	View
FKP1T014705D00KSSD	WIMA, 4700pF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial,	View
FKP1T016805F00MSSD	WIMA, 6800pF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial,	View
FKP1Y021006F00JSSD	WIMA, 10000pF Film Capacitor 700V 6000V (6kV) Polypropylene (PP), Metallized Radial,	View
FKP1T006804B00JSC9	WIMA, 680pF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial,	View
FKP1U006804C00JSSD	WIMA, 680pF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
FKP1R013304C00MSSD	WIMA, 3300pF Film Capacitor 600V 1250V (1.25kV) Polypropylene (PP), Metallized Radial,	View
FKP1R011504B00KSSD	WIMA, 1500pF Film Capacitor 600V 1250V (1.25kV) Polypropylene (PP), Metallized Radial,	View
FKP1U013305D00MSC9	WIMA, 3300pF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
FKP1G023304F00JSSD	WIMA, 0.033µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial,	View
FKP1Y011505D00MSSD	WIMA, 1500pF Film Capacitor 700V 6000V (6kV) Polypropylene (PP), Metallized Radial,	View

FKP1U003304C00JSSD

Part NumberFKP1U003304C00JSSD
