Categories	Capacitors / Ceramic Capacitors
Datasheet	FG Series
Standard Package	1500
Manufacturer	TDK Corporation
Series	FG
Packaging	Tape & Box (TB)
Part Status	Active
Capacitance	10µF
Tolerance	±10%
Voltage - Rated	50V
Temperature Coefficient	X7R
Operating Temperature	-55°C ~ 125°C
Features	-
Ratings	-
Applications	General Purpose
Failure Rate	-
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	0.217" L x 0.157" W (5.50mm x 4.00mm)
Height - Seated (Max)	0.276" (7.00mm)
Thickness (Max)	-
Lead Spacing	0.098" (2.50mm)
Lead Style	Formed Leads

FG20X7R1H105KNT06	TDK Corporation, 1µF ±10% 50V Ceramic Capacitor X7R Radial, FG	View
FG24C0G2E682JNT06	TDK Corporation, 6800pF ±5% 250V Ceramic Capacitor C0G, NP0 Radial, FG	View
FG22X7R2A225KNT06	TDK Corporation, 2.2µF ±10% 100V Ceramic Capacitor X7R Radial, FG	View
FG18C0G1H150JNT06	TDK Corporation, 15pF ±5% 50V Ceramic Capacitor C0G, NP0 Radial, FG	View
FG28X7R1H154KRT00	TDK Corporation, 0.15µF ±10% 50V Ceramic Capacitor X7R Radial, FG	View
FG28C0G1H070DNT06	TDK Corporation, 7pF ±0.5pF 50V Ceramic Capacitor C0G, NP0 Radial, FG	View
FG26X7R1E685KRT06	TDK Corporation, 6.8µF ±10% 25V Ceramic Capacitor X7R Radial, FG	View
FG26X7R2A105KNT06	TDK Corporation, 1µF ±10% 100V Ceramic Capacitor X7R Radial, FG	View
FG26X5R1E336MRT06	TDK Corporation, 33µF ±20% 25V Ceramic Capacitor X5R Radial, FG	View
FG28C0G2A682JRT06	TDK Corporation, 6800pF ±5% 100V Ceramic Capacitor C0G, NP0 Radial, FG	View
FG28C0G1H080DNT06	TDK Corporation, 8pF ±0.5pF 50V Ceramic Capacitor C0G, NP0 Radial, FG	View
FG28C0G1H040CNT06	TDK Corporation, 4pF ±0.25pF 50V Ceramic Capacitor C0G, NP0 Radial, FG	View

FG11X7R1H106KRT06

Part NumberFG11X7R1H106KRT06
