Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	EST1060T470MDGA View all Specification
Standard Package	1
Manufacturer	Taiyo Yuden
Series	ES, T Type
Packaging	Cut Tape (CT)
Part Status	Active
Type	Wirewound
Material - Core	Ferrite
Inductance	47µH
Tolerance	±20%
Current Rating (Amps)	2.1A
Current - Saturation	2.1A
Shielding	Shielded
DC Resistance (DCR)	98mOhm Max
Q @ Freq	-
Frequency - Self Resonant	7.2MHz
Ratings	AEC-Q200
Operating Temperature	-55°C ~ 150°C
Inductance Frequency - Test	100kHz
Features	-
Mounting Type	Surface Mount
Package / Case	Nonstandard
Supplier Device Package	-
Size / Dimension	0.398" L x 0.394" W (10.10mm x 10.00mm)
Height - Seated (Max)	0.248" (6.30mm)
