ELL-6UH330M


ELL-6UH330M

Part NumberELL-6UH330M

Manufacturer

Description

Datasheet

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

ELL-6UH330M - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package1000
ManufacturerPanasonic Electronic Components
SeriesH
PackagingTape & Reel (TR)
Part StatusLast Time Buy
TypeWirewound
Material - Core-
Inductance33µH
Tolerance±20%
Current Rating (Amps)1.1A
Current - Saturation-
ShieldingShielded
DC Resistance (DCR)130mOhm
Q @ Freq-
Frequency - Self Resonant-
Ratings-
Operating Temperature-
Inductance Frequency - Test100kHz
Mounting TypeSurface Mount
Package / CaseNonstandard
Supplier Device Package-
Size / Dimension0.252" L x 0.236" W (6.40mm x 6.00mm)
Height - Seated (Max)0.197" (5.00mm)
