Categories	Capacitors / Film Capacitors
Datasheet	ECQ-E(B) Series Datasheet
Standard Package	100
Manufacturer	Panasonic Electronic Components
Series	ECQ-E(B)
Packaging	Bulk
Part Status	Active
Capacitance	1µF
Tolerance	±5%
Voltage Rating - AC	-
Voltage Rating - DC	250V
Dielectric Material	Polyester, Metallized
Operating Temperature	-40°C ~ 105°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	0.602" L x 0.276" W (15.30mm x 7.00mm)
Height - Seated (Max)	0.591" (15.00mm)
Termination	PC Pins
Lead Spacing	0.492" (12.50mm)
Applications	General Purpose
Ratings	-
Features	-

ECQ-E2823KB	Panasonic Electronic Components, 0.082µF Film Capacitor 250V Polyester, Metallized Radial, ECQ-E(B)	View
ECQ-E2275JB	Panasonic Electronic Components, 2.7µF Film Capacitor 250V Polyester, Metallized Radial, ECQ-E(B)	View
ECQ-E2105JB	Panasonic Electronic Components, 1µF Film Capacitor 250V Polyester, Metallized Radial, ECQ-E(B)	View
ECQ-E2683JB	Panasonic Electronic Components, 0.068µF Film Capacitor 250V Polyester, Metallized Radial, ECQ-E(B)	View
ECQ-E2124KB	Panasonic Electronic Components, 0.12µF Film Capacitor 250V Polyester, Metallized Radial, ECQ-E(B)	View
ECQ-E2224KB	Panasonic Electronic Components, 0.22µF Film Capacitor 250V Polyester, Metallized Radial, ECQ-E(B)	View
ECQ-E2684JB	Panasonic Electronic Components, 0.68µF Film Capacitor 250V Polyester, Metallized Radial, ECQ-E(B)	View
ECQ-E2395JB	Panasonic Electronic Components, 3.9µF Film Capacitor 250V Polyester, Metallized Radial, ECQ-E(B)	View
ECQ-E2333KB	Panasonic Electronic Components, 0.033µF Film Capacitor 250V Polyester, Metallized Radial, ECQ-E(B)	View
ECQ-E2223JB	Panasonic Electronic Components, 0.022µF Film Capacitor 250V Polyester, Metallized Radial, ECQ-E(B)	View
ECQ-E2563KB	Panasonic Electronic Components, 0.056µF Film Capacitor 250V Polyester, Metallized Radial, ECQ-E(B)	View
ECQ-E2563JB	Panasonic Electronic Components, 0.056µF Film Capacitor 250V Polyester, Metallized Radial, ECQ-E(B)	View

ECQ-E2105JB

Part NumberECQ-E2105JB
