CTX20-1-52LP-R

Part NumberCTX20-1-52LP-R

ManufacturerEaton - Electronics Division

DescriptionFIXED IND 20UH 1.8A 82.9 MOHM TH

DatasheetLow Cost Power Inductors

Package / CaseRadial, Horizontal (Open)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description20µH Unshielded Toroidal Inductor 1.8A 82.9mOhm Max Radial, Horizontal (Open)

To learn about the specification of CTX20-1-52LP-R, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add CTX20-1-52LP-R with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of CTX20-1-52LP-R.
We are offering CTX20-1-52LP-R for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

CTX20-1-52LP-R - Product Attributes

Categories

Inductors, Coils, Chokes / Fixed Inductors

Datasheet

Low Cost Power Inductors

Standard Package

560

Manufacturer

Eaton - Electronics Division

Series

CTX

Packaging

Bulk

Part Status

Active

Type

Toroidal

Material - Core

Iron Powder

Inductance

20µH

Tolerance

±20%

Current Rating (Amps)

1.8A

Current - Saturation

2.2A

Shielding

Unshielded

DC Resistance (DCR)

82.9mOhm Max

Q @ Freq

Frequency - Self Resonant

Ratings

Operating Temperature

-40°C ~ 75°C

Inductance Frequency - Test

100kHz

Mounting Type

Through Hole

Package / Case

Radial, Horizontal (Open)

Supplier Device Package

Size / Dimension

0.358" Dia (9.10mm)

Height - Seated (Max)

0.264" (6.70mm)
