Categories	Capacitors / Ceramic Capacitors
Datasheet	CS Series, Automotive
Standard Package	1000
Manufacturer	TDK Corporation
Series	CS
Packaging	Bulk
Part Status	Active
Capacitance	680pF
Tolerance	±10%
Voltage - Rated	440VAC
Temperature Coefficient	B
Operating Temperature	-25°C ~ 125°C
Features	High Voltage
Ratings	AEC-Q200, X1, Y2
Applications	Safety, Automotive
Failure Rate	-
Mounting Type	Through Hole
Package / Case	Radial, Disc
Size / Dimension	0.335" Dia (8.50mm)
Height - Seated (Max)	-
Thickness (Max)	-
Lead Spacing	0.295" (7.50mm)
Lead Style	Formed Leads - Kinked
