Categories	Capacitors / Ceramic Capacitors
Datasheet	CKG Series, Commercial, MegaCap
Standard Package	1
Manufacturer	TDK Corporation
Series	MEGACAP, CKG
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	10µF
Tolerance	±20%
Voltage - Rated	50V
Temperature Coefficient	X7S
Operating Temperature	-55°C ~ 125°C
Features	Low ESL
Ratings	-
Applications	SMPS Filtering, Bypass, Decoupling
Failure Rate	-
Mounting Type	Surface Mount, MLCC
Package / Case	Nonstandard SMD
Size / Dimension	0.142" L x 0.102" W (3.60mm x 2.60mm)
Height - Seated (Max)	-
Thickness (Max)	0.136" (3.45mm)
Lead Spacing	-
Lead Style	-

CKG32KX7R2A474M335AJ	TDK Corporation, 0.47µF ±20% 100V Ceramic Capacitor X7R Nonstandard SMD, MEGACAP, CKG	View
CKG32KX7S2A475K335AJ	TDK Corporation, 4.7µF ±10% 100V Ceramic Capacitor X7S Nonstandard SMD, MEGACAP, CKG	View
CKG32KC0G2A683J335AH	TDK Corporation, 0.068µF ±5% 100V Ceramic Capacitor C0G, NP0 Nonstandard SMD, MEGACAP, CKG	View
CKG57KX7S2A156M335JJ	TDK Corporation, 15µF ±20% 100V Ceramic Capacitor X7S Nonstandard SMD, MEGACAP, CKG	View
CKG32KX7S1H106K335AH	TDK Corporation, 10µF ±10% 50V Ceramic Capacitor X7S Nonstandard SMD, MEGACAP, CKG	View
CKG32KX7R2E104M335AH	TDK Corporation, 0.1µF ±20% 250V Ceramic Capacitor X7R Nonstandard SMD, MEGACAP, CKG	View
CKG45NX7R2E105M500JH	TDK Corporation, 1µF ±20% 250V Ceramic Capacitor X7R Stacked SMD, 2 J-Lead, MEGACAP, CKG	View
CKG45NX7T2J474M500JH	TDK Corporation, 0.47µF ±20% 630V Ceramic Capacitor X7T Stacked SMD, 2 L-Lead, MEGACAP, CKG	View
CKG57NX7S1C107M500JJ	TDK Corporation, 100µF ±20% 16V Ceramic Capacitor X7S Stacked SMD, 2 J-Lead, MEGACAP, CKG	View
CKG57KX7R2A335K335JH	TDK Corporation, 3.3µF ±10% 100V Ceramic Capacitor X7R Nonstandard SMD, MEGACAP, CKG	View
CKG32KX7S2A335K335AH	TDK Corporation, 3.3µF ±10% 100V Ceramic Capacitor X7S Nonstandard SMD, MEGACAP, CKG	View
CKG45NX7S1H106M500JH	TDK Corporation, 10µF ±20% 50V Ceramic Capacitor X7S Stacked SMD, 2 J-Lead, MEGACAP, CKG	View

CKG32KX7S1H106M335AH

Part NumberCKG32KX7S1H106M335AH
