CIGW252010GLR68MNE

Part NumberCIGW252010GLR68MNE

ManufacturerSamsung Electro-Mechanics

DescriptionFIXED IND 680NH 5.2A 29MOHM SMD

DatasheetCIGW252010GLR68MNE Spec

Package / Case1008 (2520 Metric)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description680nH Unshielded Wirewound Inductor 5.2A 29mOhm Max 1008 (2520 Metric)

To learn about the specification of CIGW252010GLR68MNE, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add CIGW252010GLR68MNE with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of CIGW252010GLR68MNE.
We are offering CIGW252010GLR68MNE for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

CIGW252010GLR68MNE - Product Attributes

Categories

Inductors, Coils, Chokes / Fixed Inductors

Datasheet

CIGW252010GLR68MNE Spec

Standard Package

3000

Manufacturer

Samsung Electro-Mechanics

Series

CIGW

Packaging

Tape & Reel (TR)

Part Status

Active

Type

Wirewound

Material - Core

Metal Composite

Inductance

680nH

Tolerance

±20%

Current Rating (Amps)

5.2A

Current - Saturation

4.2A

Shielding

Unshielded

DC Resistance (DCR)

29mOhm Max

Q @ Freq

Frequency - Self Resonant

Ratings

Operating Temperature

-40°C ~ 125°C

Inductance Frequency - Test

1MHz

Features

Mounting Type

Surface Mount

Package / Case

1008 (2520 Metric)

Supplier Device Package

1008 (2520 Metric)

Size / Dimension

0.098" L x 0.079" W (2.50mm x 2.00mm)

Height - Seated (Max)

0.039" (1.00mm)
