Categories	Capacitors / Ceramic Capacitors
Datasheet	CGA Series, Automotive High Voltage
Standard Package	1
Manufacturer	TDK Corporation
Series	CGA
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	33pF
Tolerance	±10%
Voltage - Rated	3000V (3kV)
Temperature Coefficient	C0G, NP0
Operating Temperature	-55°C ~ 125°C
Features	-
Ratings	AEC-Q200
Applications	Automotive
Failure Rate	-
Mounting Type	Surface Mount, MLCC
Package / Case	1808 (4520 Metric)
Size / Dimension	0.177" L x 0.079" W (4.50mm x 2.00mm)
Height - Seated (Max)	-
Thickness (Max)	0.071" (1.80mm)
Lead Spacing	-
Lead Style	-
