Categories	Capacitors / Ceramic Capacitors
Datasheet	CGA Series, Automotive General Catalog
Standard Package	10000
Manufacturer	TDK Corporation
Series	CGA
Packaging	Tape & Reel (TR)
Part Status	Active
Capacitance	1000pF
Tolerance	±10%
Voltage - Rated	50V
Temperature Coefficient	X7R
Operating Temperature	-55°C ~ 125°C
Features	-
Ratings	AEC-Q200
Applications	Automotive
Failure Rate	-
Mounting Type	Surface Mount, MLCC
Package / Case	0402 (1005 Metric)
Size / Dimension	0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max)	-
Thickness (Max)	0.022" (0.55mm)
Lead Spacing	-
Lead Style	-
