Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	CBMF1608T100M View all Specification
Standard Package	3000
Manufacturer	Taiyo Yuden
Series	CB, MF Type
Packaging	Tape & Reel (TR)
Part Status	Active
Type	Wirewound
Material - Core	Ferrite
Inductance	10µH
Tolerance	±20%
Current Rating (Amps)	380mA
Current - Saturation	115mA
Shielding	Unshielded
DC Resistance (DCR)	468mOhm Max
Q @ Freq	-
Frequency - Self Resonant	32MHz
Ratings	-
Operating Temperature	-40°C ~ 105°C
Inductance Frequency - Test	2.52MHz
Mounting Type	Surface Mount
Package / Case	0603 (1608 Metric)
Size / Dimension	0.063" L x 0.031" W (1.60mm x 0.80mm)
Height - Seated (Max)	0.039" (1.00mm)
