Categories	Capacitors / Film Capacitors
Datasheet	C4AE Series
Standard Package	72
Manufacturer	KEMET
Series	C4AE
Packaging	Bulk
Part Status	Active
Capacitance	10µF
Tolerance	±5%
Voltage Rating - AC	-
Voltage Rating - DC	600V
Dielectric Material	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance)	6.8 mOhms
Operating Temperature	-40°C ~ 85°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	1.240" L x 0.748" W (31.50mm x 19.00mm)
Height - Seated (Max)	1.150" (29.20mm)
Termination	PC Pins
Lead Spacing	1.083" (27.50mm)
Applications	DC Link, DC Filtering; High Frequency, Switching
Ratings	-
Features	-

C4AEGBU4680A1XJ	KEMET, 6.8µF Film Capacitor 450V Polypropylene (PP), Metallized Radial, C4AE	View
C4AEOBW5120A3FJ	KEMET, 12µF Film Capacitor 900V Polypropylene (PP), Metallized Radial, C4AE	View
C4AEJBU4400A1XJ	KEMET, 4µF Film Capacitor 700V Polypropylene (PP), Metallized Radial, C4AE	View
C4AEGBW5500A3LJ	KEMET, 50µF Film Capacitor 450V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEHBW5400A3LJ	KEMET, 40µF Film Capacitor 600V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEHBU4330A1WJ	KEMET, 3.3µF Film Capacitor 600V Polypropylene (PP), Metallized Radial, C4AE	View
C4AEOBW5400A3NJ	KEMET, 40µF Film Capacitor 900V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEJBW5200A3JJ	KEMET, 20µF Film Capacitor 700V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEQBW4800A3FJ	KEMET, 8µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEQBW5270A3NJ	KEMET, 27µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial, C4AE	View
C4AEGBW5350A3JJ	KEMET, 35µF Film Capacitor 450V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEJBU4270A1WJ	KEMET, 2.7µF Film Capacitor 700V Polypropylene (PP), Metallized Radial, C4AE	View

C4AEHBU5100A11J

Part NumberC4AEHBU5100A11J
