Categories	Capacitors / Ceramic Capacitors
Datasheet	HV FT-CAP, C0G Dielectric, Automotive
Standard Package	300
Manufacturer	KEMET
Series	SMD Auto C0G HV
Packaging	Tape & Reel (TR)
Part Status	Active
Capacitance	0.022µF
Tolerance	±5%
Voltage - Rated	1000V (1kV)
Temperature Coefficient	C0G, NP0
Operating Temperature	-55°C ~ 125°C
Features	Low ESL, High Voltage
Ratings	AEC-Q200
Applications	Automotive
Failure Rate	-
Mounting Type	Surface Mount, MLCC
Package / Case	2824 (7260 Metric)
Size / Dimension	0.280" L x 0.240" W (7.10mm x 6.10mm)
Height - Seated (Max)	-
Thickness (Max)	0.106" (2.70mm)
Lead Spacing	-
Lead Style	-

C0805C681GCGACAUTO	KEMET, 680pF ±2% 500V Ceramic Capacitor C0G, NP0 0805 (2012 Metric), SMD Auto C0G HV	View
C1210C333JBGACAUTO	KEMET, 0.033µF ±5% 630V Ceramic Capacitor C0G, NP0 1210 (3225 Metric), SMD Auto C0G HV	View
C1206C331KCGACAUTO	KEMET, 330pF ±10% 500V Ceramic Capacitor C0G, NP0 1206 (3216 Metric), SMD Auto C0G HV	View
C0603C681JBGACAUTO	KEMET, 680pF ±5% 630V Ceramic Capacitor C0G, NP0 0603 (1608 Metric), SMD Auto C0G HV	View
C1812C822JBGACAUTO	KEMET, 8200pF ±5% 630V Ceramic Capacitor C0G, NP0 1812 (4532 Metric), SMD Auto C0G HV	View
C1206C682JBGACAUTO	KEMET, 6800pF ±5% 630V Ceramic Capacitor C0G, NP0 1206 (3216 Metric), SMD Auto C0G HV	View
C1206C121JBGACAUTO	KEMET, 120pF ±5% 630V Ceramic Capacitor C0G, NP0 1206 (3216 Metric), SMD Auto C0G HV	View
C1812C103JDGACAUTO	KEMET, 10000pF ±5% 1000V (1kV) Ceramic Capacitor C0G, NP0 1812 (4532 Metric), SMD Auto C0G HV	View
C1812C221JHGACAUTO	KEMET, 220pF ±5% 3000V (3kV) Ceramic Capacitor C0G, NP0 1812 (4532 Metric), SMD Auto C0G HV	View
C0805C151JCGACAUTO	KEMET, 150pF ±5% 500V Ceramic Capacitor C0G, NP0 0805 (2012 Metric), SMD Auto C0G HV	View
C1210C103JDGACAUTO	KEMET, 10000pF ±5% 1000V (1kV) Ceramic Capacitor C0G, NP0 1210 (3225 Metric), SMD Auto C0G HV	View
C1206C682JCGACAUTO	KEMET, 6800pF ±5% 500V Ceramic Capacitor C0G, NP0 1206 (3216 Metric), SMD Auto C0G HV	View

C2824C223JDGACAUTO

Part NumberC2824C223JDGACAUTO
