Categories	Capacitors / Ceramic Capacitors
Datasheet	C Series, Low ESL Reverse Geometry
Standard Package	1
Manufacturer	TDK Corporation
Series	C
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	2.2µF
Tolerance	±20%
Voltage - Rated	4V
Temperature Coefficient	X7S
Operating Temperature	-55°C ~ 125°C
Features	Low ESL (Reverse Geometry)
Ratings	-
Applications	Bypass, Decoupling
Failure Rate	-
Mounting Type	Surface Mount, MLCC
Package / Case	0306 (0816 Metric)
Size / Dimension	0.031" L x 0.063" W (0.80mm x 1.60mm)
Height - Seated (Max)	-
Thickness (Max)	0.024" (0.60mm)
Lead Spacing	-
Lead Style	-
