BTS7904BATMA1

Part NumberBTS7904BATMA1

ManufacturerInfineon Technologies

DescriptionMOSFET N/P-CH 55V/30V 40A TO263

DatasheetBTS7904B

Package / CaseTO-263-6, D²Pak (5 Leads + Tab), TO-263BA

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionMosfet Array N and P-Channel 55V, 30V 40A 69W, 96W Surface Mount PG-TO263-5-1

To learn about the specification of BTS7904BATMA1, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add BTS7904BATMA1 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of BTS7904BATMA1.
We are offering BTS7904BATMA1 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

BTS7904BATMA1 - Product Attributes

Categories

Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays

Datasheet

BTS7904B

Standard Package

1000

Manufacturer

Infineon Technologies

Series

OptiMOS™

Packaging

Tape & Reel (TR)

Part Status

Obsolete

FET Type

N and P-Channel

FET Feature

Logic Level Gate

Drain to Source Voltage (Vdss)

55V, 30V

Current - Continuous Drain (Id) @ 25°C

40A

Rds On (Max) @ Id, Vgs

11.7mOhm @ 20A, 10V

Vgs(th) (Max) @ Id

2.2V @ 40µA

Gate Charge (Qg) (Max) @ Vgs

121nC @ 10V

Input Capacitance (Ciss) (Max) @ Vds

6100pF @ 25V

Power - Max

69W, 96W

Operating Temperature

-55°C ~ 150°C (TJ)

Mounting Type

Surface Mount

Package / Case

TO-263-6, D²Pak (5 Leads + Tab), TO-263BA

Supplier Device Package

PG-TO263-5-1
