Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - RF
Datasheet	BLP8G10S-270PW
Standard Package	1
Manufacturer	Ampleon USA Inc.
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
Transistor Type	LDMOS (Dual), Common Source
Frequency	718.5MHz ~ 765.5MHz
Gain	20dB
Voltage - Test	28V
Current Rating (Amps)	-
Noise Figure	-
Current - Test	2A
Power - Output	56W
Voltage - Rated	65V
Package / Case	SOT-1221-2
Supplier Device Package	6-HSOPF
